AMX PC1

The PC1 control provides one switched outlet for 120 VAC power control with up to 1200 W of equipment power.

Ideal for giving power control over devices that may not be easily controlled via Infrared or other control signal types.

Manuals

	Phiên bản	Kích thước	Đã tải lên
Quick Start Guide - PC1 Power Controller phiên bản D, cập nhật: Thg 7 2018	D	100 KB	Thg 7 2018

CAD Drawings

	Kích thước	Đã tải lên
Pictorial Drawing - PC1 Power Controller (PDF) cập nhật: Thg 7 2018	80 KB	Thg 7 2018
Pictorial Drawing - PC1 Power Controller (DXF) cập nhật: Thg 7 2018	100 KB	Thg 7 2018
Pictorial Drawing - PC1 Power Controller (DWG) cập nhật: Thg 7 2018	60 KB	Thg 7 2018

BIM Objects

	Kích thước	Đã tải lên
PC1 - BIM Object cập nhật: Thg 8 2019		Thg 8 2019

Nếu bất kỳ liên kết nào ở trên hiển thị ký tự lạ trong trình duyệt của bạn, vui lòng nhấp chuột phải vào tệp để lưu vào máy tính của bạn.

Dimensions (HWD)	1 1/2" x 5 1/2" x 5 1/2" (3.8 cm x 14 cm x 14 cm) RU: 1
Weight	1 lb, 12 oz (793 g)
Power Requirements	Power Input: 105 to 125 VAC, 3 watts maximum (internal electronics) Power Outputs: 1 switched 3-wire sockets, 120 VAC, 1,200 watts total
Control Ports	Either one latched or two momentary closures for discrete on and off, or one momentary closure for toggling on and off Switched AC receptacle, 10 A at 120 VAC
Load Fuse	Internal 10 A (load capacity)
Control Inputs	Remote control contact and switch closure
Enclosure Material	Metal with black matte finish
Type	AC switched power control unit
Front Panel Components	AC1 power switch controls power to a switched socket. The LED in the pushbutton indicates that socket power is ON DIP Switch: Controls the AC1 (and AC2) push button operating mode, depending on the setting of the switches
Rear Panel Components	AC Power Input: 3-conductor line cord providing 120 VAC power to the power control unit and to switched power sockets Switched Power: Socket for control of external equipment having a total power load of 1,200 watts. An internal 10 A load fuse is provided (The PC2 has 2 power sockets) Control: 4-pin captive-wire connector providing remote operation of the power control units. Terminals accept 24 – 12 AWG wire
Power cables	6 ft (1.83 m) cord with 3-wire grounded plug
FG Numbers	FG670
