PC1

Power Controller, 10 A (110 VAC only)

PC1

The PC1 control provides one switched outlet for 120 VAC power control with up to 1200 W of equipment power.

Common Applications

Ideal for giving power control over devices that may not be easily controlled via Infrared or other control signal types.

Downloads

  Version Language Size Uploaded
Manuals
file type icon Quick Start Guide - PC1 Power Controller
version D, updated: Jul 2018
  137 KB Jul 2018
CAD Drawings
file type icon Pictorial Drawing - PC1 Power Controller (PDF)
updated: Jul 2018
    79.9 KB Jul 2018
file type icon Pictorial Drawing - PC1 Power Controller (DXF)
updated: Jul 2018
    132 KB Jul 2018
file type icon Pictorial Drawing - PC1 Power Controller (DWG)
updated: Jul 2018
    58.7 KB Jul 2018
Bim Objects
file type icon PC1 - BIM Object
updated: Aug 2019
    Aug 2019

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Features

  • Front-panel on/off button with status LED
  • DIP switch to set closure mode

Specifications

Dimensions (HWD)
  • 1 1/2" x 5 1/2" x 5 1/2" (3.8 cm x 14 cm x 14 cm)
  • RU: 1
Weight
  • 1 lb, 12 oz (793 g)
Power Requirements
  • Power Input: 105 to 125 VAC, 3 watts maximum (internal electronics)
  • Power Outputs: 1 switched 3-wire sockets, 120 VAC, 1,200 watts total
Control Ports
  • Either one latched or two momentary closures for discrete on and off, or one momentary closure for toggling on and off
  • Switched AC receptacle, 10 A at 120 VAC
Load Fuse Internal 10 A (load capacity)
Control Inputs Remote control contact and switch closure
Enclosure Material Metal with black matte finish
Type AC switched power control unit
Front Panel Components
  • AC1 power switch controls power to a switched socket. The LED in the pushbutton indicates that socket power is ON
  • DIP Switch: Controls the AC1 (and AC2) push button operating mode, depending on the setting of the switches
Rear Panel Components
  • AC Power Input: 3-conductor line cord providing 120 VAC power to the power control unit and to switched power sockets
  • Switched Power: Socket for control of external equipment having a total power load of 1,200 watts. An internal 10 A load fuse is provided (The PC2 has 2 power sockets)
  • Control: 4-pin captive-wire connector providing remote operation of the power control units. Terminals accept 24 – 12 AWG wire
Power cables 6 ft (1.83 m) cord with 3-wire grounded plug
FG Numbers FG670
