MXA-FMK-20 (停产)

适于 20.3" Modero X® 系列壁挂式触控面板的嵌入式安装套件

MXA-FMK-20

该产品已停产,预计最后订购日期为 2019 年 3 月 31 日。

利用 MXA-FMK-20 嵌入式安装套件可将 Modero X 20.3" 壁挂式触控面板完全嵌装到墙壁之中或嵌装在正常的墙壁安装位置(前提是需要操作侧面按钮和增强扬声器的传播性能)。MXA-FMK-20 兼容所有 Modero X 20.3” 壁挂式触控面板,包括 MXD-2001-PAN-P (FG5968-36)、MXD-2001-PAN-L (FG5968-37)、MXD-2000XL-PAN-P (FG5968-05)、MXD-2000XL-PAN-L (FG5968-11)、MXD-2000XL-PAN-P-NC (FG5968-33) 和 MXD-2000XL-PAN-L-NC (FG5968-34)。请注意,MXA-FMK-20 属于独立安装解决方案,不与布线盒等安装硬件配合使用。

下载

  Version Language Size Uploaded
CAD Drawings
file type icon Mounting Spec - MXA-FMK-20 Flush Mount Kit for 20.3" Modero X Series Wall Mount Touch Panels (PDF)
updated: 10月 2020
    364.7 KB 10月 2020
file type icon Mounting Spec - MXA-FMK-20 Flush Mount Kit for 20.3" Modero X Series Wall Mount Touch Panels (DXF)
updated: 10月 2020
    801.9 KB 10月 2020
BIM Objects
file type icon MXA-FMK-20 - BIM Object
updated: 8月 2019
    8月 2019
Quick Start Guides
file type icon Quick Start Guide - MXA-FMK-20 Modero X Series Flush Mount Kit
version B, updated: 10月 2020
  302.4 KB 10月 2020
Whitepapers
file type icon AMX AV/IT Administrator's Guide
updated: 10月 2020
    2.6 MB 10月 2020

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

性能

尺寸(高宽厚) 10 5/16” x 20 7/8” x 3” (261.82 mm x 530.32 mm x 76.2 mm)
重量 8.45 lbs (3.83 kg)

随附配件

  • (10) 6-32 x .375 screws (80-0137-03)
  • (8) trim frame spacers (66-5968-47)
  • MXA-FMK-20 Flush Mount Kit Template (68-5968-09)
  • MXA-FMK-20 Quick Start Guide (93-5968-68)
FG Numbers FG5968-68
