NMX-ACC-N9206

适于六台 SVSI N 系列卡单元的 2RU 机架安装插件框架(含电源)

NMX-ACC-N9206

2RU 机架安装插件框架(含电源),用于将多达六个 SVSI N 系列编码器、解码器和音频收发器卡安装到机架。卡由 PoE(以太网供电)和/或使用随附的 Phoenix 接口电缆将卡的 12VDC 输入连接到插件框架 12VDC 输出供电。

警告:必须为 N9206 供电才能为已安装的卡提供足够的冷却。未将插件框架连接到交流电源将导致保修失效。

Videos





下载

  Version Language Size Uploaded
CAD Drawings
file type icon Pictorial Drawing (DWG) – NMX-ACC-N9206
updated: 7月 2020
    782.9 KB 7月 2020
file type icon Pictorial Drawing (PDF) – NMX-ACC-N9206
updated: 7月 2020
    375.6 KB 7月 2020
Software
platform icon SVSI SNMP MIB
updated: 7月 2020
    9.8 KB 7月 2020
Data Sheets
file type icon Data Sheet - NMX-ACC-N9206, 2RU Rack Mount Cage, Six SVSI N-Series Card Units
updated: 10月 2020
    353.6 KB 10月 2020
Quick Start Guides
file type icon Quick Start Guide - NMX-ACC-N9206 Cage, 2RU, 6 N-Series Card Units
updated: 10月 2020
    130.9 KB 10月 2020
Install Guides
file type icon SVSI Networked AV - Pre-Implementation Guide
updated: 8月 2023
    1.2 MB 8月 2023
Product Guides
file type icon Product Guide - N-Series Minimum Network Requirement
version B, updated: 10月 2023
  165.6 KB 10月 2023

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

性能

尺寸(高宽厚) 3.40" x 17.22" x 5.04" (8.63 cm x 43.73 cm x 12.8 cm)
重量 7.61 lbs (3.45 kg)
认证 FCC, CE, and NTRL

随附配件

Qty-3 NMX-ACC-N9210, plate to cover unpopulated slots (FGN9210)

电源

  • Input: 100-240 Volts @ 1 Amp AC power supply
  • Output: 12VDC @ up to 15A (total over all 6 Phoenix Connectors)
FG Numbers FGN9206
