板载控制 – 所有 N 系列编码器和解码器均配备板载内置控制功能,通过事件可触发对其他 IP 可控设备的任意数量的 TCP/UDP 命令
无限扩展
独立或插卡 - 可用作独立设备,或插卡以与 NMX-ACC-N9206 配合使用
性能
Video
Signal Types
Video Input: Network video over Ethernet via RJ45 port
Video Output: HDMI, DVI-D (through adapter)
Formats
HDMI, DVI-D (through adapter), HDCP content protection support
Output Resolutions
Supports most common HD up to 4096x2160. See website for all supported resolutions.
Audio
Signal Types
Input Signal Types: Network audio over Ethernet via RJ45
Output Signal Types: Embedded audio on DVI-D or HDMI (through adapter)
HDMI Audio Formats: 8ch PCM
Analog Audio Format: Stereo 2-channel
Digital-to-Analog Conversion: 16-bit 32 kHz, 44.1 kHz and 48 kHz (matched to network audio stream settings)
滞后时间
Uncompressed:
25 ms at 60 fps
50 ms at 30 fps
JPEG2000:
50 ms at 60 fps
100 ms at 30 fps
Note: This is the combined encode plus decode latency. Total latency from source to screen will also include any network latency.
Note: Scaling adds one frame of latency (16ms at 60fps)
Configurations
Ethernet
P0: 10/100/1000 Mbps, auto-negotiating, auto-sensing, full/half duplex, DHCP, Auto IP, and Static IP
P1: Full duplex, DHCP, Auto IP, and Static IP 10 Gbps port which accepts compatible fiber transceivers or direct attach cables (fiber or copper cabling)
Ports
+12V 2A: One 12 Volt DC power input
P0
8-wire RJ45 female
10/100/1000 Mbps 10/100/1000Base-T auto-sensing gigabit Ethernet switch port
Provides network control connections and compressed network AV output
P1
SFP+ port (SFP+ fiber transceiver or direct attach cable not included) for uncompressed or compressed networked AV and allows network control connections
IR
2-pin terminal Phoenix connector
Provides Infrared (IR) output only (33-60 kHz; typically 39 kHz). Emitter may be necessary (not included)
RS232
3-pin terminal Phoenix connector
Provides a serial control interface. Full duplex communication. Available terminal speed settings: 9600-115200 baud rate
AUDIO
5-pin terminal Phoenix connector
Dedicated audio output
HDMI OUT: HDMI video output
USB connectors (front panel): USB-B control input and two USB-A control inputs Currently only the USB-A connectors are supported in software for HID devices
Controls and Indicators - Front Panel
RESET Button
Recessed pushbutton
Hold 30 seconds for a factory reset of all settings, including IP address settings
Press to initiate a 'warm restart' causing the processor to reset, but not lose power. A reset does NOT affect the current settings
ID Button
Recessed pushbutton
Press to send a notification out on the network to identify the unit (the notification causes a pop-up dialog in N-Able and N-Command)
POWER LED
On solid (green) when operating power is supplied (via PoE or local power supply)
This activity is also shown by the PWR LED on the rear panel
STATUS LED
On flashing (green) when there is software activity
This activity is also shown by the STAT LED on the rear panel
Controls and Indicators - Rear Panel
PWR LED: Same as POWER LED described above
HDMI LED: On (green) when there is a connection to a valid display
STAT LED: Same as STATUS LED described above
STRM LED: On (green) when the unit is streaming video
General
Regulatory Compliance: FCC, CE, and NTRL
Recommended Accessories:
NMX-ACC-N9206 (FGN9206), 2RU Rack Mount Cage with Power for Six SVSI N-Series Card Units
兼容的 AMX 产品
Audio/video content sent from the encoder is compatible with the following products:
NMX-ENC-N2151 (FGN2151-XX) JPEG 2000 4K UHD Video over IP Encoder with KVM
