The PSR2.5 power supply provides 2.5 A of DC power at 24VDC, and ships as an included accessory with the MXR-1001 Modero X® Series G5 Retractable Touch Panel. It includes a 3-position 3.5 mm Phoenix Connector with retention screws.
下载
| Size | ||||
Quick Start Guides | ||||
Quick Start Guide - PS/N/R Power Supplies
updated: 10月 2020
|
666.7 KB | |||
If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.
性能
| 尺寸（高宽厚） | 4 3/4" x 2 3/8" x 1 1/4" (12 cm x 6 cm x 3.05 cm) |
| 重量 | 1.1 lb (499 g) |
| 输入电压 | ~100-240 V |
| Input Frequency | 47-63 Hz |
| Input Current | 1.5A MAX |
| Output Voltage | 24 VDC |
| Output Current | 2.5A |
| Ripple and Noise | 300 mV peak-to-peak @ full load |
| 保护 | Over-voltage, over-current, short-circuit, over temperature, overload protected |
| Power Indicator | Green LED indicates the presence of DC on the output |
| 接头 | 3-pin retained captive wire connector (3.5mm) |
| Power cables | 4-foot (1.2 m) IEC power cord terminated with a grounded Edison plug for AC input (US only). |
| 音箱材料 | Molded black matte plastic |
| 环境 | Operating Temperature: 32°F to 104°F (0°C to 40°C) |
| 认证 |
|
| SKU Numbers | FG423-47 |
