PSR2.5

24VDC, 2.5A Power Supply with 3.5mm Phoenix Connector with Retention Screws


The PSR2.5 power supply provides 2.5 A of DC power at 24VDC, and ships as an included accessory with the MXR-1001 Modero X® Series G5 Retractable Touch Panel.  It includes a 3-position 3.5 mm Phoenix Connector with retention screws.

Downloads

  Version Language Size Uploaded
Quick Start Guides
file type icon Quick Start Guide - PS/N/R Power Supplies
updated: Oct 23
    667 KB Oct 23

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Specifications

Dimensions (HWD) 4 3/4" x 2 3/8" x 1 1/4" (12 cm x 6 cm x 3.05 cm)
Weight 1.1 lb (499 g)
Input Voltage ~100-240 V
Input Frequency 47-63 Hz
Input Current 1.5A MAX
Output Voltage 24 VDC
Output Current 2.5A
Ripple and Noise 300 mV peak-to-peak @ full load
Protection Over-voltage, over-current, short-circuit, over temperature, overload protected
Power Indicator Green LED indicates the presence of DC on the output
Connectors 3-pin retained captive wire connector (3.5mm)
Power cables 4-foot (1.2 m) IEC power cord terminated with a grounded Edison plug for AC input (US only).
Enclosure Material Molded black matte plastic
Environmental Operating Temperature: 32°F to 104°F (0°C to 40°C)
Certification
  • UL: US listed - Class I Power Supply
  • CUL approved
  • TUV-GS approved
  • FCC approved
  • CE approved
  • PSE approved
  • CCC approved
  • BSMI approved
  • RCM approved
SKU Numbers FG423-47
