• Signal Types
• Digital Video Input: HDMI, DVI-D*, Dual-Mode DisplayPort (DP++)*
• Analog Video Input: HD-15 VGA, Component*
• Video Output: Network video over Ethernet via RJ45 port or via 10G SFP+ port, HDMI, DVI-D*

*Note: these signal types are supported through a passive adapter.

• Formats
• HDMI, DVI-D*, Dual-Mode DisplayPort (DP++)*, HDCP content protection support, RGBHV, YPbPr

*Note: these signal types are supported through a passive adapter.

• Progressive Input Resolutions
• HDMI and DVI (Progressive)
• Pixel clock between 54 MHz - 300 MHz
• Minimum resolution of 1024x768
• Maximum horizontal resolution of 4096 or a vertical resolution of 2160*
• Common acceptable resolutions include: 1024x768p60, 1280x720@60Hz - 720p60, 1600x1200@60Hz, 1920x1080@60Hz - 1080p60, 2560x1440@30Hz - QHD30, 3840x2160@30Hz - UHD30 aka 4K30, 3840x2160(4:2:0)@50Hz (JPEG2000 only), 3840x2160(4:2:0)@60Hz (JPEG2000 only), 4096x2160(4:2:2)@30Hz - DCI 4K30, 4096x2160(4:2:0)@60Hz (JPEG2000 only)

• Interlaced Input Resolutions
• HDMI and DVI (Interlaced)
• 1920x1080@50Hz - 1080i50 (JPEG2000 only)
• 1920x1080@60Hz - 1080i60 (JPEG2000 only)

Note: Interlaced resolutions will be de-interlaced.

• Analog Input Resolutions
• VGA
• Pixel clock between 54 MHz - 165 MHz
• Minimum resolution of 1024x768
• Maximum horizontal resolution of 1920 or a vertical resolution of 1200
• Common acceptable resolutions include: 1024x768@60Hz, 1280x720@50Hz (720p50), 1280x720@60Hz (720p60), 1280x768@60Hz, 1280x800@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1440x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1080@50Hz (1080p50), 1920x1080@60Hz (1080p60), 1920x1200@60Hz (reduced blanking)
• Component
• HD up to 1080p60
• 1920x1080@50Hz - 1080i50 (JPEG2000 only)
• 1920x1080@60Hz - 1080i60 (JPEG2000 only)

• Output Resolutions: Matched to inputs*

*Note: Input resolutions supported @60Hz refresh rates are also supported @59.94Hz

*Note: The N2151 Encoder does not accept Composite or S-Video (YC)

• Color Space
• 4:2:2 Resolutions up to 4K30
• 4:2:0 4K60

• Signal Types
• Input: Embedded audio on HDMI (DVI-D through adapter) or Analog Stereo (Balanced or Unbalanced)
• Output: Ethernet, Embedded audio on HDMI or DVI-D (through adapter)*

*HDMI output refers to pass-through video on the HDMI OUT port

• Formats
• HDMI: 8ch PCM
• Analog: Stereo 2-channel
• Analog-To-Digital Conversion: 16-bit 32 kHz, 44.1 kHz and 48 kHz

Uncompressed:

• 25 ms at 60 fps
• 50 ms at 30 fps

JPEG2000:

• 50 ms at 60 fps
• 100 ms at 30 fps

Note: This is the combined encode plus decode latency. Total latency from source to screen will also include any network latency

Note: Scaling adds one frame of latency (17ms at 60fps)

• Uncompressed: 4000 Mb/s at 4K30 4:2:2
• JPEG2000: 200 to 600 Mb/s*
• Recommend 200-300 Mb/s for motion video
• Recommend 500-600 Mb/s for computer graphics
• *Note: Minimum bandwidth is 50 Mb/s for resolutions <= 1080p60

• Ethernet
• PO
• 10/100/1000 Mbps, auto-negotiating, auto-sensing, full/half duplex, DHCP, Auto IP, and Static IP
• P1
• 10 Gbps port which accepts compatible fiber transceivers or direct attach cables
• HDMI: HDCP, EDID management

• +12V 2A: One 12 Volt DC power input
• PO
• 8-wire RJ45
• 10/100/1000 Mbps 10/100/1000Base-T auto-sensing gigabit Ethernet switch port
• Provides the network connection and JPEG2000 compressed video
• P1
• 10 Gb/s SFP+ port (SFP+ fiber transceiver or direct attach cable not included)
• Provides the network connection and uncompressed networked AV video
• IR
• 2-pin terminal Phoenix connector
• Provides Infrared (IR) output only (33-60 kHz; typically 39 kHz). Emitter may be necessary (not included)
• RS232
• 3-pin terminal Phoenix connector
• Provides a serial control interface. Full duplex communication. Available terminal speed settings: 9600-115200 baud rate
• AUDIO
• 5-pin terminal Phoenix connector
• Provides user-selectable balanced/unbalanced input. Dedicated audio input
• HDMI OUT: HDMI video output (passive pass-through from HDMI IN)
• HDMI IN: HDMI video input
• VGA IN: DB15 analog input
• USB connectors (front panel): USB-B control input and two USB-A control inputs

• RESET Button
• Recessed pushbutton
• Press to initiate a 'warm restart' causing the processor to reset, but not lose power. A reset does NOT affect the current settings
• ID Button
• Recessed pushbutton
• Press to send a notification out on the network to identify the unit (the notification causes a pop-up dialog in N-Able and N-Command)
• POWER LED
• On solid (green) when operating power is supplied (via PoE or local power supply)
• This activity is also shown by the PWR LED on the rear panel
• STATUS LED
• On flashing (green) when there is software activity
• This activity is also shown by the STAT LED on the rear panel

• PWR LED: Same as POWER LED described above
• HDMI LED: On (green) when there is a connection to a valid video source
• STAT LED: Same as STATUS LED described above
• STRM LED: On (green) when the unit is streaming video

• Regulatory Compliance: FCC, CE, and NTRL
• Recommended Accessories: NMX-ACC-N9206 (FGN9206), 2RU Rack Mount Cage with Power for Six SVSI N-Series Card Units
