NMX-ENC-N2151-C Encoder Card (discontinued)

JPEG 2000 4K UHD Video over IP Encoder with KVM, Card

NMX-ENC-N2151-C Encoder Card

The NMX-ENC-N2151 4K Encoder and NMX-DEC-N2251 4K Decoder provide users with the industry's most versatile solution for distributing AV over a converged network at resolutions up to 4096×2160. JPEG2000 compression allows Ultra HD media to be switched and distributed over standard Gigabit Ethernet networks. Ultra HD signals from the NMX-ENC-N2151 encoder are provided simultaneously as: 1) a JPEG2000-compressed 200-600 Mbps stream through the RJ45 connector or small-form-pluggable (SFP+) port (10Gb), and 2) an uncompressed stream through the SFP+ connector (via a fiber module). Any source can be sent to any number of displays by routing through layer-3 switches. System scalability is limited only by uplink and stacking connector bandwidths.

Standard features like output scaling (decoder), bi-directional serial, IR output, embedded 7.1 audio, and KVM-over-IP extension are included. The NMX-ENCN2151-C and NMX-DEC-N2251-C form-factors are compatible with the NMX-ACCN9206 card cage for high-density applications.

Common Applications

The NMX-ENC-N2151 and NMX-DEC-N2251 together create the perfect solution for video matrix applications where resolutions up to 4K are required. Common applications include classrooms, conference rooms, performing arts centers, and sports bars.

Videos





















Downloads

  Version Language Size Uploaded
Manuals
file type icon NetLinx Control for N-Series Products Documentation Addendum
updated: Oct 2020
    1.05 MB Oct 2020
file type icon Instruction Manual - NMX-ENC-N2151 / NMX-DEC-N2251 JPEG 2000 4K UHD Video over IP Encoder with KVM
updated: Jun 2020
    7.72 MB Jun 2020
Software
platform icon SVSI SNMP MIB
updated: Jul 2020
    9.8 KB Jul 2020
platform icon SVSI N-Able PC
version 5.1.6, updated: Jan 2024
5.1.6     114 MB Jan 2024
Firmware
platform icon SVSI N2x51 Encoder and Decoder Firmware Updater
version 1.5.3f, updated: Nov 2021
1.5.3f     64.4 MB Nov 2021
Data Sheets
file type icon NMX-ENC-N2151, JPEG 2000 4K UHD Video over IP Encoder with KVM
updated: Jul 2018
    741 KB Jul 2018
Install Guides
file type icon SVSI Networked AV - Pre-Implementation Guide
updated: Aug 2023
    1.15 MB Aug 2023
Quick Start Guides
file type icon Quick Start Guide - NMX-ENC-N2151 / NMX-DEC-N2251 JPEG 2000 4K UHD Video over IP Encoder with KVM
updated: Mar 2018
    334 KB Mar 2018
Programming Guides
file type icon API Command List - SVSI N1000/N2000 Series
version F, updated: Jun 2020
  277 KB Jun 2020
Product Guides
file type icon Product Guide - N-Series Video Wall/Crop Limitation
updated: Oct 2020
    72.8 KB Oct 2020
file type icon Product Guide - N-Series Minimum Network Requirement
version B, updated: Oct 2023
  166 KB Oct 2023
file type icon N-Series Stream Compatibility
updated: Feb 2024
    431 KB Feb 2024

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Features

  • Output Scaling — Video scaling at the output (decoder) allows seamless switching from any source, at any resolution, to any display or projector, while preserving video fidelity
  • Infrared (IR) — Infrared emitter connection allows control of low-cost, IR-only display devices
  • Onboard Control — All N-Series encoders and decoders have on-board, built-in control capability via events that can trigger any number of TCP/UDP commands to other IP controllable devices
  • Pass-through HDMI interface (encoder) — allows easy installation with local display such as desktop PC applications
  • Unlimited Scalability — Grow the video matrix by adding encoders or decoders as needed (within the bandwidth limits of the uplink and stacking connectors
  • Stand Alone or Card — Available as a stand-alone device, or card for use with NMX-ACC-N9206.

Specifications

Video
  • Signal Types
      • Digital Video Input: HDMI, DVI-D*, Dual-Mode DisplayPort (DP++)*
      • Analog Video Input: HD-15 VGA, Component*
      • Video Output: Network video over Ethernet via RJ45 port or via 10G SFP+ port, HDMI, DVI-D*

*Note: these signal types are supported through a passive adapter.

  • Formats
      • HDMI, DVI-D*, Dual-Mode DisplayPort (DP++)*, HDCP content protection support, RGBHV, YPbPr

*Note: these signal types are supported through a passive adapter.

  • Progressive Input Resolutions
    • HDMI and DVI (Progressive)
      • Pixel clock between 54 MHz - 300 MHz
      • Minimum resolution of 1024x768
      • Maximum horizontal resolution of 4096 or a vertical resolution of 2160*
      • Common acceptable resolutions include: 1024x768p60, 1280x720@60Hz - 720p60, 1600x1200@60Hz, 1920x1080@60Hz - 1080p60, 2560x1440@30Hz - QHD30, 3840x2160@30Hz - UHD30 aka 4K30, 3840x2160(4:2:0)@50Hz (JPEG2000 only), 3840x2160(4:2:0)@60Hz (JPEG2000 only), 4096x2160(4:2:2)@30Hz - DCI 4K30, 4096x2160(4:2:0)@60Hz (JPEG2000 only)
  • Interlaced Input Resolutions
      • HDMI and DVI (Interlaced)
        • 1920x1080@50Hz - 1080i50 (JPEG2000 only)
        • 1920x1080@60Hz - 1080i60 (JPEG2000 only)

Note: Interlaced resolutions will be de-interlaced.

  • Analog Input Resolutions
      • VGA
        • Pixel clock between 54 MHz - 165 MHz
        • Minimum resolution of 1024x768
        • Maximum horizontal resolution of 1920 or a vertical resolution of 1200
        • Common acceptable resolutions include: 1024x768@60Hz, 1280x720@50Hz (720p50), 1280x720@60Hz (720p60), 1280x768@60Hz, 1280x800@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1440x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1080@50Hz (1080p50), 1920x1080@60Hz (1080p60), 1920x1200@60Hz (reduced blanking)
      • Component
        • HD up to 1080p60
        • 1920x1080@50Hz - 1080i50 (JPEG2000 only)
        • 1920x1080@60Hz - 1080i60 (JPEG2000 only)
  • Output Resolutions: Matched to inputs*

*Note: Input resolutions supported @60Hz refresh rates are also supported @59.94Hz

*Note: The N2151 Encoder does not accept Composite or S-Video (YC)

  • Color Space
    • 4:2:2 Resolutions up to 4K30
    • 4:2:0 4K60
Audio
  • Signal Types
      • Input: Embedded audio on HDMI (DVI-D through adapter) or Analog Stereo (Balanced or Unbalanced)
      • Output: Ethernet, Embedded audio on HDMI or DVI-D (through adapter)*

*HDMI output refers to pass-through video on the HDMI OUT port

  • Formats
    • HDMI: 8ch PCM
    • Analog: Stereo 2-channel
  • Analog-To-Digital Conversion: 16-bit 32 kHz, 44.1 kHz and 48 kHz
Latency

Uncompressed:

  • 25 ms at 60 fps
  • 50 ms at 30 fps



JPEG2000:

  • 50 ms at 60 fps
  • 100 ms at 30 fps



Note: This is the combined encode plus decode latency. Total latency from source to screen will also include any network latency

Note: Scaling adds one frame of latency (17ms at 60fps)

Bandwidth
  • Uncompressed: 4000 Mb/s at 4K30 4:2:2
  • JPEG2000: 200 to 600 Mb/s*
    • Recommend 200-300 Mb/s for motion video
    • Recommend 500-600 Mb/s for computer graphics
  • *Note: Minimum bandwidth is 50 Mb/s for resolutions <= 1080p60
Communications
  • Ethernet
    • PO
      • 10/100/1000 Mbps, auto-negotiating, auto-sensing, full/half duplex, DHCP, Auto IP, and Static IP
    • P1
      • 10 Gbps port which accepts compatible fiber transceivers or direct attach cables
  • HDMI: HDCP, EDID management
Ports
  • +12V 2A: One 12 Volt DC power input
  • PO
    • 8-wire RJ45
    • 10/100/1000 Mbps 10/100/1000Base-T auto-sensing gigabit Ethernet switch port
    • Provides the network connection and JPEG2000 compressed video
  • P1
    • 10 Gb/s SFP+ port (SFP+ fiber transceiver or direct attach cable not included)
    • Provides the network connection and uncompressed networked AV video
  • IR
    • 2-pin terminal Phoenix connector
    • Provides Infrared (IR) output only (33-60 kHz; typically 39 kHz). Emitter may be necessary (not included)
  • RS232
    • 3-pin terminal Phoenix connector
    • Provides a serial control interface. Full duplex communication. Available terminal speed settings: 9600-115200 baud rate
  • AUDIO
    • 5-pin terminal Phoenix connector
    • Provides user-selectable balanced/unbalanced input. Dedicated audio input
  • HDMI OUT: HDMI video output (passive pass-through from HDMI IN)
  • HDMI IN: HDMI video input
  • VGA IN: DB15 analog input
  • USB connectors (front panel): USB-B control input and two USB-A control inputs
Controls and Indicators - Front Panel
  • RESET Button
    • Recessed pushbutton
    • Press to initiate a 'warm restart' causing the processor to reset, but not lose power. A reset does NOT affect the current settings
  • ID Button
    • Recessed pushbutton
    • Press to send a notification out on the network to identify the unit (the notification causes a pop-up dialog in N-Able and N-Command)
  • POWER LED
    • On solid (green) when operating power is supplied (via PoE or local power supply)
    • This activity is also shown by the PWR LED on the rear panel
  • STATUS LED
    • On flashing (green) when there is software activity
    • This activity is also shown by the STAT LED on the rear panel
Controls and Indicators - Rear Panel
  • PWR LED: Same as POWER LED described above
  • HDMI LED: On (green) when there is a connection to a valid video source
  • STAT LED: Same as STATUS LED described above
  • STRM LED: On (green) when the unit is streaming video
General
  • Regulatory Compliance: FCC, CE, and NTRL
  • Recommended Accessories: NMX-ACC-N9206 (FGN9206), 2RU Rack Mount Cage with Power for Six SVSI N-Series Card Units
FG Numbers FGN2151-CD
