MX-AC-TMPLT-MXR10 (discontinued)

Installation Router Guide

MX-AC-TMPLT-MXR10

The Installation Router Guide is a sturdy, re-usable cutting template to simplify the installation of a Modero X® G5 Retractable Touch Panel (MXR-1001). Use this template for cutting the table or lectern, ensuring a correct fit every time.

Router Guide is only compatible with the following router hardware (accessories not included):

  • Router Bit: Freud 12-128 or Whiteside 1072
  • Router Guide Bushing: Woodcraft 144693
  • Router Lock Nut: Woodcraft 144696

Downloads

  Version Language Size Uploaded
Quick Start Guides
file type icon Quick Start Guide - MX-AC-TMPLT-MXR10
updated: Oct 2020
    6.4 MB Oct 2020

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Specifications

FG Numbers FG5968-90
