MXA-RMK-07 (discontinued)

Rack Mount Kit for 7" Modero X Series Landscape Touch Panel

The MXA-RMK-07 Rack Mount Kit is an optional accessory for 7" Modero X Series Wall Mount Touch Panels that allow these panels to be mounted directly to an equipment rack. The kit includes a rack mount frame, screws and washers. It is compatible MXD-701-L (FG5968-55), with MXD-700-L (FG5968-14) and MXD-700-L-NC (FG5968-29).

Downloads

  Version Language Size Uploaded
CAD Drawings
    118 KB Oct 22, 2020
    190 KB Oct 22, 2020
    150 KB Oct 22, 2020
    1.6 MB Oct 22, 2020
    447 KB Oct 22, 2020
Quick Start Guides
  307 KB Oct 22, 2020
Whitepapers
AMX AV/IT Administrator's Guide
updated: Oct 23, 2020
    2.61 MB Oct 23, 2020

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Specifications

Dimensions (HWD) 7" x 19" x 2 1/16" (177.0 mm x 482.6 mm x 53.1 mm)
Weight 2.75 lbs (1.25 kg)
Included Accessories
  • MXA-RMK- 07 Installation Guide (93-5969-63)
  • Rack Mount Panel, 7" Modero Wall Touch Panel (62-5968-43)
  • Screws, #10-32 PFH 1.75" Long, Black (4) (80-5968-01)
  • Screws, #6-32 x .375, PPH, Black (4) (80-0138)
  • Washers, #6, Flat, 3/8 Diameter, .03 Thick, Stainless Steel (4)(80-0322-01)
FG Numbers FG5969-63
