NT-SD-701 (discontinued)

7" N-Touch Wall Mount Touch Panel


Replacement Products

  • VARIA-80


    8” Professional-Grade, Persona-Defined Touch Panel

The NT-SD-701 and NT-ST-701 N-Touch Panels allow you to easily add a control interface to your SVSI system. Each touch panel combines a high-quality user interface and controller into a single unit, enabling user control of SVSI devices in conference rooms, classrooms, and other types of spaces.

With a generous selection of mounting options, the NT-SD-701 can be placed on any flat surface (including glass) inside a conference room or classroom. Key features include control of network-based devices, a brilliant 24-color depth, and PoE connectivity – all at an economical price point.

Common Applications

The NT-SD-701 is ideal for any application requiring intuitive control of network connected video streams and devices. For example, in a meeting room or classroom the user can select and switch video streams to the display, and in an operations center the user can change the video wall layout.


  Version Language Size Uploaded
file type icon Configuration Options Guide - SVSI N-Touch
version A, updated: Jul 2018
  1.98 MB Jul 2018
file type icon Tutorial - SVSI N-Touch Panel Builder
updated: Jul 2018
    1.29 MB Jul 2018
platform icon Panel Builder Standalone
version 2017-05-01 / v1.23.50, updated: May 2018
2017-05-01 / v1.23.50     46.4 MB May 2018
platform icon SVSI N-Able PC
version 2023-09-03, updated: Sep 2023
2023-09-03     191 MB Sep 2023
platform icon N-Touch Series Touch Panel Firmware Updater
version 2017-05-01 (PB: v1.23.50), updated: Nov 2021
2017-05-01 (PB: v1.23.50)     24.8 MB Nov 2021
Data Sheets
file type icon 7" N-Touch Wall Mount Touch Panel
updated: Jul 2018
    324 KB Jul 2018
Programming Guides
file type icon Scripting Tutorial - SVSI N-Touch Panel Builder
updated: Jul 2018
    144 KB Jul 2018

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.


  • Easily Control SVSI Systems – Select which stream is playing, start and stop recordings, or change windowing presets from an elegant user interface on the table or wall.
  • Control and User Interface in One – Control network-based devices directly from the touch panel - no additional equipment is required.
  • Built-In Design Tools – Design and program the user interface directly on the unit using only a web browser.
  • Scripting Made Simple – Build simple scripts using drop-down menus, and expand them with all the flexibility offered by a full programming language.
  • Versatile Mounting Options– Install a Wall Mount panel using the included back-box, or use an accessory Mount Kit to mount the panel to glass, standard single- and dual-gang boxes, or equipment racks.


Touch Screen Display
  • Display Type: TFT Active Matrix Color LCD with Fringe Field Switching (FFS) - Wide Viewing Angle Technology
  • Display Size (WH): 7.3" x 4.8" (186 mm x 122 mm), 8.8" (222 mm) diagonal
  • Viewable Area (WH): 6.05" x 3.54" (154 mm x 90 mm), 7.0" (178 mm) diagonal
  • Resolution (WH): 1024x600
  • Aspect Ratio (WH): 16:9
  • Brightness: 400 cd/m2
  • Contrast Ratio: 800:1
  • Color Depth: 16.7M colors
  • Illumination: LED
  • Touch Overlay: Resistive
  • Viewing Angle: 89°/89°/89°/89° (Up/Down/Left/Right)
  • SDRAM: 512 MB
  • Flash: 4 GB
  • Maximum Project Size: 1 GB flash available to user
  • ETHERNET: 10/100 port, RJ-45 connector. Supported IP and IP-Based Protocols: UDP, TCP, DHCP, HTTP, HTTPS
  • USB: (1) USB host 2.0, Type A port: future use
  • Microphone: -42dB ± 3dB sensitivity FET microphone
  • Speakers: 4 ohm, 1.5 Watt, 500Hz cutoff frequency
Graphics Engine
  • SVSI N-Touch: The UI Engine is the SVSI N-Touch technology, based on HTML5 and Javascript
Front Panel Components
  • Top Button: Use top button for factory restoration
  • Red/Green LEDs: Programmable LEDs on left and right side.
  • Ethernet: 10/100 port, RJ-45 connector
  • USB: (1) USB host 2.0, Type A port
  • Power: PoE (Power over Ethernet), 802.3af, class 0
  • Temperature (Operating): 32° F to 104° F (0° C to 40° C)
  • Temperature (Storage): 4° F to 140° F (20° C to 60° C)
  • Humidity (Operating): 20% to 85% RH
  • Humidity (Storage): 5% to 85% RH
  • Power ("Heat") Dissipation
    • On: 27.3 BTU/hr
    • Standby: 10.9 BTU/hr
  • Dimensions (HWD): 4 7/8” x 7 3/8” x 2 1/4” (123.9 mm x 187.5 mm x 58 mm), with back box
  • Weight:
    • 1.05 lbs (.680 Kg), with back box
    • 0.8 lbs (.363 Kg), without back box
  • Power Consumption
    • Full-On: 11 W (max)
    • Typical: 7 W
    • Standby: 4.5 W
    • Shutdown: 0.7 W
    • Start-Up Inrush Current: Not applicable due to PoE standard
  • External Power Supply Required: Optimal performance requires use of one of the following AMX PoE power supplies (not included): PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
  • Certifications
    • FCC Part 15 Class B
    • CE EN 55022
    • CE EN 55024
    • CE EN 60950-1
    • IEC 60950-1
    • IC CISPR 22 Class B
    • C-Tick CISPR 22 Class B
    • UL 60950-1
    • VCCI CISPR 22 Class B
    • RoHS
    • WEEE
  • Included Accessories
    • Wall Mounting Template
    • Backbox, Wall Mount, 7"
  • Optional Accessories
    • PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
    • CB-MXSA-07, Rough-In Box and Cover Plate for the 7" Wall Mount Modero X/S Series Touch and Acendo Book Panels (FG4221-07)
    • MSA-MMK2-07, Multi Mount Kit, for use with MSD-701-L2, ACB-2107 (FG4221-07)
    • MSA-RMK-07, Rack Mount Kit for 7" Modero S Series Wall Mount Touch Panel (FG2265-15)
    • MSA-AMK2-07, Any Mount Kit, for use with MSD-701-L2, ACB-2107 (FG4221-07)
    • MXA-CLK, Modero X/S Series Screen Cleaning Kit (FG5968-16)
    • MXA-USB-C, USB Port Covers (FG5968-18)
FG Numbers FGN8307-SD
