NT-ST-701 (discontinued)

7" N-Touch Tabletop Touch Panel

NT-ST-701

The NT-SD-701 and NT-ST-701 N-Touch Panels allow you to easily add a control interface to your SVSI system. Each touch panel combines a high-quality user interface and controller into a single unit, enabling user control of SVSI devices in conference rooms, classrooms, and other types of spaces.

The NT-ST-701 has a sleek design that remains affordable due to its ruggedized plastic housing. Key features include control of network-based devices, a brilliant 24-color depth, and PoE connectivity – all at an economical price point.

Common Applications

The NT-ST-701 is ideal for any application requiring intuitive control of network connected video streams and devices. For example, in a meeting room or classroom the user can select and switch video streams to the display, and in an operations center the user can change the video wall layout.

Downloads

  Version Language Size Uploaded
Manuals
file type icon Configuration Options Guide - SVSI N-Touch
version A, updated: Jul 2018
  1.98 MB Jul 2018
file type icon Tutorial - SVSI N-Touch Panel Builder
updated: Jul 2018
    1.29 MB Jul 2018
Software
platform icon Panel Builder Standalone
version 2017-05-01 / v1.23.50, updated: May 2018
2017-05-01 / v1.23.50     46.4 MB May 2018
platform icon SVSI N-Able PC
version 5.1.6, updated: Jan 2024
5.1.6     114 MB Jan 2024
Firmware
platform icon N-Touch Series Touch Panel Firmware Updater
version 2017-05-01 (PB: v1.23.50), updated: Nov 2021
2017-05-01 (PB: v1.23.50)     24.8 MB Nov 2021
Data Sheets
file type icon 7" N-Touch Tabletop Touch Panel
updated: Jul 2018
    324 KB Jul 2018
Programming Guides
file type icon Scripting Tutorial - SVSI N-Touch Panel Builder
updated: Jul 2018
    144 KB Jul 2018

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Features

  • Easily Control SVSI Systems – Select which stream is playing, start and stop recordings, or change windowing presets from an elegant user interface on the table or wall.
  • Control and User Interface in One – Control network-based devices directly from the touch panel - no additional equipment is required.
  • Built-In Design Tools – Design and program the user interface directly on the unit using only a web browser.
  • Scripting Made Simple – Build simple scripts using drop-down menus, and expand them with all the flexibility offered by a full programming language.
  • Secure Table Mounting Option– Our beautifully styled secure mounting plate attaches to the Modero S tabletop touch panels and secures with under-table tamper resistant bolts making it virtually theft proof.
  • Optional Kensington Mount – If it's not possible or desirable to mount the touch panel to the table, the secure plate can also be used in conjunction with a Kensington Lock.

Specifications

Touch Screen Display
  • Display Type: TFT Active Matrix Color LCD with Fringe Field Switching (FFS) - Wide Viewing Angle Technology
  • Display Size (WH): 7.3" x 4.8" (186 mm x 122 mm), 8.8" (222 mm) diagonal
  • Viewable Area (WH): 6.05" x 3.54" (154 mm x 90 mm), 7.0" (178 mm) diagonal
  • Resolution (WH): 1024x600
  • Aspect Ratio (WH): 16:9
  • Brightness: 400 cd/m2
  • Contrast Ratio: 800:1
  • Color Depth: 16.7M colors
  • Illumination: LED
  • Touch Overlay: Resistive
  • Viewing Angle: 89°/89°/89°/89° (Up/Down/Left/Right)
Memory
  • SDRAM: 512 MB
  • Flash: 4 GB
  • Maximum Project Size: 1 GB flash available to user
Communications
  • ETHERNET: 10/100 port, RJ-45 connector. Supported IP and IP-Based Protocols: UDP, TCP, DHCP, HTTP, HTTPS
  • USB: (1) USB host 2.0, Type A port: future use
Audio
  • Microphone: -42dB ± 3dB sensitivity FET microphone
  • Speakers: 4 ohm, 1.5 Watt, 500Hz cutoff frequency
Graphics Engine
  • SVSI N-Touch: The UI Engine is the SVSI N-Touch technology, based on HTML5 and Javascript
Front Panel Components
  • Top Button: Sleep Button: Sleep button to activate sleep mode and powering off. Also provides access to setup pages (can be disabled)
Connections
  • Ethernet: 10/100 port, RJ-45 connector
  • USB: (1) USB host 2.0, Type A port
  • Power: PoE (Power over Ethernet), 802.3af, class 0
Environmental
  • Temperature (Operating): 32° F to 104° F (0° C to 40° C)
  • Temperature (Storage): 4° F to 140° F (20° C to 60° C)
  • Humidity (Operating): 20% to 85% RH
  • Humidity (Storage): 5% to 85% RH
  • Power ("Heat") Dissipation
    • On: 27.3 BTU/hr
    • Standby: 10.9 BTU/hr
General
  • Dimensions (HWD): 4 1/2" x 7 3/8" x 3 3/16" (115 mm x 188 mm x 81 mm)
  • Weight: 1.4 lbs (.635 Kg)
  • Power Consumption
    • Full-On: 13 W (max)
    • Typical: 7 W
    • Standby: 4.5 W
    • Shutdown: 0.7 W
  • External Power Supply Required: Optimal performance requires use of one of the following AMX PoE power supplies (not included): PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
  • Certifications
    • FCC Part 15 Class B
    • CE EN 55022
    • CE EN 55024
    • CE EN 60950-1
    • IEC 60950-1
    • IC CISPR 22 Class B
    • C-Tick CISPR 22 Class B
    • UL 60950-1
    • VCCI CISPR 22 Class B
    • RoHS
    • WEEE
  • Included Accessories
    • MXA-USB-C, USB Port Cover Kit, Modero X Series Touch Panel (FG5968-18)
    • Cat5e Ethernet Cable, Flat Black (ECA2265-10)
    • UTP CAT.5E Snap In Coupler, Black (64-5968-01)
  • Optional Accessories
    • MSA-STMK-07, Secure Table Mount Kit, 7" Modero S Tabletop (FG2265-17)
    • PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
    • HPG-10-10K, 3/4" Mini-Grommet, 10-Pack (FG570-01-10K)
    • MXA-CLK, Modero X/S Series Screen Cleaning Kit (FG5968-16)
    • MXA-USB-C, USB Port Covers (FG5968-18)
