NMX-DEC-N2235A-C Decoder Card (discontinued)

JPEG 2000 1080p Low-Latency Decoder with KVM PoE, SFP, HDMI, AES67 Support, Card

NMX-DEC-N2235A-C Decoder Card

The SVSI JPEG2000 NMX-ENC-N2135A-C and NMX-DEC-N2235A-C encoder and decoder solution provides users with the industry’s most versatile solution for distributing AV over a converged network. JPEG2000 compression is the codec of choice for users demanding low-latency cinema grade HD quality video in their system. SVSI video over IP encoders are used to encode and distribute sources of almost any format onto an existing IP network making that stream available to any endpoint in the facility utilizing copper and/or fiber connectivity. SVSI Video over IP Decoders are used to decode Networked AV streams for display. With the ability to direct any source stream to any display, large, low-cost switching and distribution systems are simple to deploy without proprietary cabling or dedicated switching hardware. User selectable bandwidth control (10Mbps-600Mbps) allows for precision tuning considering network load and video quality.

The NMX-ENC-N2135A-C and NMX-DEC-N2235A-C both feature keyboard and mouse extension over IP. Users can set security options for device control. Security can be turned off allowing any decoder to connect to any computer connected to an encoder – for example within a call center where security of this type is not an issue and access to all end points is necessary. Security can be set allowing access to only specified computers or defined groups of computers – sensitive environments such as command and control centers benefit from this kind of customized security.

The SVSI solution allows for any number of inputs to connect to any number of outputs creating a video matrix of unlimited size and expandability. Plug-n-play, auto-detect technology reduces installation and programming time and all SVSI encoders and decoders include built in control capability.

Videos





















Downloads

  Version Language Size Uploaded
Manuals
file type icon NetLinx Control for N-Series Products Documentation Addendum
updated: Oct 2020
    1.05 MB Oct 2020
Software
platform icon SVSI N-Able PC
version 5.1.6, updated: Jan 2024
5.1.6     114 MB Jan 2024
platform icon SVSI N-Able Mac
version 5.1.4, updated: Feb 2024
5.1.4     240 MB Feb 2024
Firmware
platform icon SVSI N2x35A Encoder and Decoder Firmware Updater
version 1.15.18, updated: Nov 2021
1.15.18     44.7 MB Nov 2021
Product Guides
file type icon N-Series Stream Compatibility
updated: Feb 2024
    431 KB Feb 2024
file type icon Product Guide - N-Series Minimum Network Requirement
version B, updated: Oct 2023
  166 KB Oct 2023
file type icon NET-SVSI-MIB.txt
updated: Aug 2021
    94.5 KB Aug 2021
file type icon Product Guide - N-Series Video Wall/Crop Limitation
updated: Oct 2020
    72.8 KB Oct 2020
Programming Guides
file type icon Zoom Room Controls – SVSI Decoder Configuration Example
version 0.1.5, updated: Sep 2021
0.1.5    132 KB Sep 2021
file type icon API Command List - SVSI N1000/N2000 Series
version F, updated: Jun 2020
  277 KB Jun 2020
Quick Start Guides
file type icon Quick Start Guide Guide - SVSI N2135A/N2235A Keyboard and Mouse Series
updated: Sep 2018
    328 KB Sep 2018
file type icon Quick Start Guide - NMX-ENC-N2135 / NMX-DEC-N2235 JPEG 2000 Video over IP LAN Solutions
updated: Mar 2018
    339 KB Mar 2018
Install Guides
file type icon SVSI Networked AV - Pre-Implementation Guide
updated: Aug 2023
    1.15 MB Aug 2023

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Features

  • Design Flexibility – Compatible with all SVSI N2000 series products so designers can choose the right product for each end point
  • Input and Output Scaling – Scaling performed in encoders or decoders for maximum flexibility with sources and displays
  • Power Over Ethernet (POE) – Eliminates requirement for local power supply and speeds installation. Units can still be powered locally from 12VDC allowing for easy rack-mountable, high-density installations
  • Infrared (IR) – Emitter connection allows control of IR-only display devices
  • Fast Install – With Phoenix connectors for Power, IR, RS232 serial, and analog audio (balanced and unbalanced) interfaces
  • Balanced and Unbalanced Audio – Embedded 7.1 audio (balanced and unbalanced)
  • HDMI with HDCP – Pass protected HDMI content
  • Multiple Connection Options – RJ-45 and SFP network connectors and HDMI video connections
  • KVM – Single USB-B and Dual USB-A control for KVM applications
  • Control Flexibility – Built-in or external control

Specifications

Video
  • Video Input: Network video over copper via RJ45 port or fiber via 1G SFP port
  • Video Output: HDMI, DVI-D (through adapter)
  • Formats: HDMI, DVI-D (through adapter), HDCP content protection support
  • Input Resolutions
    • Supports most common HD up to 1920x1200.
      • **720x480@59Hz, 640x480@60Hz, **720x480@60Hz, **720x576@50Hz, 800x600@56Hz, 800x600@60Hz, **1280x720@50Hz, **1280x720@59Hz, **1280x720@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1024x768@60Hz, 1280x800@60Hz, 1152x864@60Hz, 1600x900@60Hz, 1440x900@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1680x1050@60Hz, 1920x1080@23Hz, 1920x1080@24Hz, 1920x1080@25Hz, 1920x1080@29Hz, 1920x1080@30Hz, **1920x1080@50Hz, **1920x1080@59Hz, **1920x1080@60Hz, **1920x1080i@50Hz, **1920x1080i@59Hz, **1920x1080i@60Hz, ***1920x1200@60Hz



**supported in component mode

***reduced blanking only

Audio
  • Input Signal Types: Network audio over Ethernet (audio at 48-kHz, standard SVSI audio stream or AES67, user selectable)
  • Output Signal Types: Embedded audio on HDMI or DVI-D (through adapter)
  • HDMI Audio Formats: 8ch PCM
  • Analog Audio Format: Stereo 2-channel
Latency
  • Video Latency: 50 ms at 60 fps
  • Audio Latency: standard SVSI audio stream = 17 ms (synced to video); AES67 = <1 ms adjustable to 17 ms



Note: This is the combined encode plus decode latency. Total latency from source to screen will also include any network latency.

Note: Scaling adds one frame of latency (17ms at 60fps)

Communications
  • Ethernet
    • PO: 10/100/1000 Mbps, auto-negotiating, auto-sensing, full/half duplex, DHCP, Auto IP, and Static IP
    • P1: 1 Gbps port which accepts compatible fiber transceivers or direct attach cables (fiber or copper cabling)
  • HDMI: HDCP, EDID management
Ports
  • +12V 2A: One 12 Volt DC power input.
  • P0
    • 8-wire RJ45 female.
    • 10/100/1000 Mbps 10/100/1000Base-T auto-sensing gigabit Ethernet switch port
    • Provides the network connection, network AV video, and power to the Encoders and Decoders
  • P1
    • SFP port (SFP fiber transceiver or direct attach cable not included)
    • Provides the network connection and network AV video
  • IR
    • 2-pin terminal Phoenix connector
    • Provides Infrared (IR) output only (33-60 kHz; typically 39 kHz). Emitter may be necessary (not included).
  • RS232
    • 3-pin terminal Phoenix connector
    • Provides a serial control interface. Full duplex communication. Available terminal speed settings: 9600-115200 baud rate
  • AUDIO
    • 5-pin terminal Phoenix connector
    • Provides user-selectable balanced/unbalanced output. Dedicated audio output
  • HDMI OUT: HDMI video output
  • USB connectors (front panel): One USB-B and two USB-A control inputs
Controls and Indicators - Front Panel
  • RESET button
    • Recessed pushbutton
    • Press to initiate a 'warm restart' causing the processor to reset, but not lose power. A reset does NOT affect the current settings
  • ID button
    • Recessed pushbutton
    • Press to send a notification out on the network to identify the unit (the notification causes a pop-up dialog in N-Able and N-Command)
  • POWER LED
    • On solid (green) when operating power is supplied (via PoE or local power supply)
    • This activity is also shown by the PWR LED on the rear panel
  • STATUS LED
    • On flashing (green) when there is software activity
    • This activity is also shown by the STAT LED on the rear panel
Controls and Indicators - Rear Panel
  • PWR LED: Same as POWER LED described above
  • HDMI LED: On (green) when there is a connection to a valid video display
  • STAT LED: Same as STATUS LED described above
  • STRM LED: On (green) when the unit is streaming video
Environmental
  • Temperature: 32° to 104°F (0° to 40°C)
  • Humidity: 10% to 90% RH (non-condensing)
  • Heat Dissipation: Up to ~44 BTU/hr
General
  • Regulatory Compliance: FCC, CE, and NTRL
  • Recommended Accessories:
    • NMX-ACC-N9206 (FGN9206), 2RU Rack Mount Cage with Power for Six SVSI N-Series Card Units
FG Numbers FGN2235A-CD
