NMX-DEC-N1233A-C Decoder Card

Minimal Proprietary Compression Video Over IP Decoder with KVM AES67 Support, Card

Limited Availability
NMX-DEC-N1233A-C Decoder Card

The new NMX-DEC-N1233A-C provides the functionality of the NMX-DEC-N1233A in a card form factor for use with the NMX-ACC-N9206 2RU Rack Mount Cage, providing a clean rack mount solution for multiple encoders and decoders. It features improved digital pixel reproduction and reduces latency to an industry leading 10-ms for gigabit links. Packetized video streams not only remain visually lossless throughout distribution, they also arrive instantly. It has separate HDMI and VGA/RGB inputs, supports PoE AES67, and has a separate SFP port. The SFP fiber path allows visually lossless video to be routed on a fiber-only network and extend signals beyond the reach of category cable. Added USB connectivity will enable users to extend USB over IP for touch-enabled and KVM applications.

The N1000 Series Encoders and Decoders are an affordable local AV over IP switching solution that packetizes video into a minimally compressed IP format to create anywhere from a small 2×1 seamless presentation switcher up to a mid-size matrix switcher by connecting them directly to off-the-shelf network switches.

Common Applications

The NMX-DEC-N1233A-C is the perfect solution for any low-latency application, particularly scenarios with a live presentation when the presenter is using a keyboard and mouse like in a conference room or classroom.

Videos





















Downloads

  Version Language Size Uploaded
Manuals
file type icon NetLinx Control for N-Series Products Documentation Addendum
updated: Oct 2020
    1.05 MB Oct 2020
Software
platform icon SVSI N-Able PC
version 5.1.6, updated: Jan 2024
5.1.6     114 MB Jan 2024
platform icon SVSI N-Able Mac
version 5.1.4, updated: Feb 2024
5.1.4     240 MB Feb 2024
Firmware
platform icon SVSI N1x33A Encoder and Decoder Firmware Updater
version 1.15.45, updated: Nov 2021
1.15.45     42.9 MB Nov 2021
Quick Start Guides
file type icon Quick Start Guide - SVSI N1000 MPC Series
updated: Oct 2018
    369 KB Oct 2018
Programming Guides
file type icon API Command List - SVSI N1000/N2000 Series
version F, updated: Jun 2020
  277 KB Jun 2020
file type icon Zoom Room Controls – SVSI Decoder Configuration Example
version 0.1.5, updated: Sep 2021
0.1.5    132 KB Sep 2021
Install Guides
file type icon SVSI Networked AV - Pre-Implementation Guide
updated: Aug 2023
    1.15 MB Aug 2023
Product Guides
file type icon Product Guide - N-Series Video Wall/Crop Limitation
updated: Oct 2020
    72.8 KB Oct 2020
file type icon NET-SVSI-MIB.txt
updated: Aug 2021
    94.5 KB Aug 2021
file type icon Product Guide - N-Series Minimum Network Requirement
version B, updated: Oct 2023
  166 KB Oct 2023
file type icon N-Series Stream Compatibility
updated: Feb 2024
    431 KB Feb 2024

If any of the links above result in strange characters in your browser, please right-click the file to save it to your computer.

Features

  • Output Scaling – Video scaling at output allows seamless switching from any source, at any resolution, to any display or projector, while preserving video fidelity
  • 1 Frame Latency – Same as HDBaseT
  • Minimal Proprietary Compression (MPC) – Visually lossless MPC algorithm applied to all resolutions
  • Optional Compression – Available option to disable all compression
  • Power Over Ethernet (PoE) – PoE eliminates the need for power supply
  • Infrared (IR) – Infrared emitter connection allows control of low-cost, IR-only display devices
  • Onboard Control – All N-Series encoders and decoders have on-board, built-in control capability via events that can trigger any number of TCP/UDP commands to other IP controllable devices
  • Unmatched Flexibility – Highly competitive pricing for matrices up to 32x32, or higher with the help of our design experts
  • SFP Fiber/RJ45 Ports – Encoder features SFP fiber/RJ45 copper network ports with USB control inputs for KVM-over-IP keyboard and mouse operation.
  • Stand Alone or Card – Available as a stand alone device, or card for use with NMX-ACC-N9206

Specifications

Video
  • Digital Video Input: Network video over Ethernet via RJ45 port or fiber via 1G SFP port
  • Video Output: HDMI, DVI-D (through adapter)
  • Formats: HDMI, DVI-D (through adapter), HDCP content protection support
  • Output Resolutions:
    • Supports most common HD up to 1920x1200.
      • **720x480 @ 59Hz, 640x480 @ 60Hz, **720x480 @ 60Hz, **720x576 @ 50Hz, 800x600 @ 56Hz, 800x600 @ 60Hz, **1280x720 @ 50Hz, **1280x720 @ 59Hz, **1280x720 @ 60Hz, 1360x768 @ 60Hz, 1366x768 @ 60Hz, 1024x768 @ 60Hz, 1280x800 @ 60Hz, 1152x864 @ 60Hz, 1600x900 @ 60Hz, 1440x900 @ 60Hz, 1280x960 @ 60Hz, 1280x1024 @ 60Hz, ***1600x1200 @ 60Hz, 1680x1050 @ 60Hz, 1920x1080 @ 23Hz, 1920x1080 @ 24Hz, 1920x1080 @ 25Hz, 1920x1080 @ 29Hz, 1920x1080 @ 30Hz, **1920x1080 @ 50Hz, **1920x1080 @ 59Hz, **1920x1080 @ 60Hz, **1920x1080i @ 50Hz, **1920x1080i @ 59Hz, **1920x1080i @ 60Hz, ***1920x1200 @ 60Hz



**supported in component mode

***reduced blanking only

Audio
  • Input Signal Types: Network video and audio over Ethernet via RJ45 (audio at 48-kHz, standard SVSI audio stream or AES67, user selectable)
  • Output Signal Types: Embedded audio on DVI-D or HDMI (through adapter)
  • HDMI Audio Formats: 8ch PCM
  • Analog Audio Format: Stereo 2-channel
  • Digital-to-Analog Conversation: 16-bit 32 kHz, 44.1 kHz and 48 kHz (matched to Encoder settings)
Latency
  • Video Latency: 10 ms at 60 fps
  • Audio Latency: standard SVSI audio stream = 17 ms(synced to video); AES67 = <1 ms adjustable to 17 ms



Note: This is the combined encode plus decode latency. Total latency from source to screen will also include any network latency.

Note: Scaling adds one frame of latency (17ms at 60fps)

Communications
  • Ethernet:
    • P0: 10/100/1000 Mbps, auto-negotiating, auto-sensing, full/half duplex, DHCP, Auto IP, and Static IP
    • P1: 1 Gbps port which accepts compatible fiber transceivers or direct attach cables (fiber or copper cabling)
Ports
  • +12V 2A: One 12 Volt DC power input
  • P0:
    • 8-wire RJ45 female
    • 10/100/1000 Mbps 10/100/1000Base-T auto-sensing gigabit Ethernet switch port
    • Provides the network connection to the Encoders and Decoders
  • P1:
    • SFP port (SFP fiber transceiver or direct attach cable not included) for MPC compressed networked AV video
    • Provides network connection to the Encoders and Decoders
  • IR:
    • 2-pin terminal Phoenix connector
    • Provides Infrared (IR) output only (33-60 kHz; typically 39 kHz). Emitter may be necessary (not included)
  • RS232:
    • 3-pin terminal Phoenix connector
    • Provides a serial control interface. Full duplex communication. Available terminal speed settings: 9600-115200 baud rate
  • Audio:
    • 5-pin terminal Phoenix connector
    • Provides user-selectable balanced/unbalanced output. Dedicated audio output
  • HDMI Out: HDMI video output
  • USB connectors (front panel): USB-B control input and two USB-A control inputs
Controls and Indicators - Front Panel
  • RESET Button:
    • Recessed pushbutton
    • Press to initiate a 'warm restart' causing the processor to reset, but not lose power. A reset does NOT affect the current settings
  • ID Button:
    • Recessed pushbutton
    • Press to send a notification out on the network to identify the unit (the notification causes a pop-up dialog in N-Able and N-Command)
  • POWER LED:
    • On solid (green) when operating power is supplied (via PoE or local power supply)
    • This activity is also shown by the PWR LED on the rear panel
  • STATUS LED:
    • On flashing (green) when there is software activity
    • This activity is also shown by the STAT LED on the rear panel
Controls and Indicators - Rear Panel
  • PWR LED: Same as POWER LED described above
  • HDMI LED: On (green) when there is a connection to a valid video source
  • STAT LED: Same as STATUS LED described above
  • STRM LED: On (green) when the unit is streaming video
Environmental
  • Temperature: 32° to 104°F (0° to 40°C)
  • Humidity: 10% to 90% RH (non-condensing)
  • Heat Dissipation: Up to ~44 BTU/hr
General
  • Regulatory Compliance: FCC, CE, and NTRL
  • Recommended Accessories: NMX-ACC-N9206 (FGN9206), 2RU Rack Mount Cage with Power for Six SVSI N-Series Card Units
FG Numbers FGN1233A-CD
